7. SPECIFICATIONS
KEY FEATURES
Power RMS 4 Ohm	4×25 W
Radio tuner type	AM, FM, RDS
Number of RCA outputs	8
Number of radio stations	18 FM, 12 AM
AUX input	3.5 mm mini-jack
Card reader	ME. 20 Sonly for models DB 510DSP and DB520DSP
USB ports	USB Type-A + USB charging port (5V, 1A)
Supported audio playback formats	MP3, WMA, AAC, FLAC, WAV
Head Unit steering wheel control buttons learning (SWC)	Yes
Hands-Free support	Yes
CONNECTION
Working voltage	10-17 V
Input terminal connection	16 AWG
Output terminal connection	20 AWG
Automatic turn on/off	ACC
Front panel backlight type	ARGB, 7 colors
Quantity of backlight zones	2
Information screen type	VA LCD
Integrated fuse	15A
AUDIO
Built in amplifier class AB
Number of RCA outputs	8
Number of full range RCA outputs	6
Number of subwoofer RCA outputs	2
RCA output voltage	up to 4.5 V
Bluetooth profile	A2DP
Frequency response for full range channels	20 Hz- 20 kHz
Frequency response for subwoofer channels	20 Hz- 800 Hz
Signal to noise ratio	≥80 dB
Minimum permissible load impedance on the single channel	4 Ohm

CROSSOVER
Filter types for full range channels	LPF, HPF
Filter types for subwoofer channels	LPF, HPF
Crossover frequency for full range channels	30 H2 – 12.5 KHZ
Crossover frequency for subwoofer channels	20 Hz- 800 Hz
Filter slope for full range channels	6-24 dB/Oct
